HORIZONTAL MULTISTAGE CENTRIFUGAL ELECTRIC PUMPS
AISI 304
Horizontal multistage centrifugal electric pumps in AISI 304 stainless steel suitable for industrial washing, pressure boosting units, industrial plants, distribution and treatment of water, heating and air conditioning, cooling and chiller, irrigation and recovery of rain water. Strong and compact construction. Available in various versions and models.
Specifications
• Temperature of the liquid: from -15°C to +110°C
• Temperature of the liquid: from -15°C to +85°C for WRAS version
• Maximum working pressure: 10 bar
• Maximum chlorine content: 500 ppm
Materials
• Pump body, impellers, intermediate stages, seal housing disc and shaft (part in contact with the liquid) in AISI 304
• Mechanical sealing in Carbon/Ceramic/EPDM
• Support and motor casing in aluminium
Technical document
• Self-ventilated 2 pole asynchronous motor
• Class of insulation F
• IP55 Protection rating
• 230V ±10%, 50Hz single phase voltage, 230/400V ±10%, 50Hz three phase voltage
• Permanent capacitor inserted and thermo-amperometric protection with automatic rearm incorporated for the single phase motor
• Protection under user's responsibility for the three phase version
• G1 suction connection for MATRIX 3, G1¼ for MATRIX 5, G1½ for MATRIX 10, G2 for MATRIX 18
• G1 discharge connection for MATRIX 3-5, G1¼ for MATRIX 10, G1½ for MATRIX 18
Total head [m3/h] min 1.20 max 27.00
Total head [m] max 97.00 min 5.20
