Specifications
Maximum working pressure : 8 bar
°Maximum liquid temperature: 60°C for CD 70/05-70/07-90/10
90°C for other models
110°C for H and HS versions
Materials
Pump body,impeller,diffuser, casing cover, bracket,motor casing and fan cover in AISI 304
°Shaft in AISI 303
°Mechanical seal in carbon/ceramic/NBR
ceramic/carbon/FPM for CDH
SIC/SIC/FPM for CDHS
°Special mechanical seal are available on demand
Technical document
T.E.F.C. 2 poles motor
°Insulation class F
°Protection degree IP55
°1~230V ± 10% 50Hz, 3~230/400V ± 10% 50Hz
°Permanent split capacitor and automatic thermal overload protection for single-phase version
°Thermal protection to be provided by the user for three-phase version
°DNA 1"½ for CD200, DNA 1"¼ for the other models
° DNM 1"
